SIB 350
Feature
Txhua yam khoom ntawm XMlite muaj nws txoj kev lag luam pom tseeb. Piv txwv li, qhov no MEGABEAM350
Hauv xyoo 2017, thaum txhua tus neeg tsim khoom tau teeb tsa 3-hauv-1 hybrid txav lub taub hau teeb saum toj 20R nrog CMY, XMlite pom tias raws li cov txiaj ntsig kev lag luam thiab cov kev xav tau tiag tiag: txawm hais tias feem ntau cov kev ua yeeb yam loj yuav siv. teeb siab tshaj 440W, tab sis siab dua 20R Lub teeb tus nqi kuj yog siab, thiab ntau qhov kev ua tau zoo tsis xav tau qhov ci ntsa iab. Hauv kev ua lag luam hauv qab 440W, muaj qee qhov kev thov rau lub teeb nrog CMY ib yam, tab sis muaj ob peb lub Hoobkas tsim lub teeb nrog CMY qis dua 400W ntawm kev ua lag luam. Raws li kev tshawb nrhiav saum toj no, XMlite tau pib MEGABEAM350W 3 in1 hybrid txav taub hau teeb nrog CMY muaj nuj nqi hauv 2017.
MEAGBEAM350 muab cov nqaj, ntxuav thiab qhov chaw hauv ib qho, thiab nws tau nruab nrog CMY muaj nuj nqi. Lub kaum sab xis ncav cuag 37 degrees, thiab ib lub teeb tuaj yeem npog thaj tsam loj ntawm theem. Lub kaum sab xis me me kuj tuaj yeem tswj tau ntawm 4 degrees, thiab cov nyhuv beam yog huv si thiab ntse. Xav txog tus nqi, lub plug-in CMY system raug tso tseg, thiab lub teb CMY system raug xaiv. Nrog rau txoj haujlwm tsim nyog, cov xim hloov pauv tuaj yeem ua tiav lawm thiab cov xim tuaj yeem hloov tau sai.
1. Cov txheej txheem kho qhov muag zoo tshaj plaws, cov qauv yog qhov tseeb thiab tsis sib xws, thiab cov nqaj yog ntse;
2. Nrog ob chav prism superposition nyhuv, nrog CMY muaj nuj nqi;
3. Siv lub tshuab magnetic coding positioning, XY axis positioning yog qhov tseeb thiab cov lus teb ceev ceev.
Specification
Channels hom | 21/25CH; |
Teeb | YODN MSD350 M17; |
Hwj chim | AC 200-240V, 50/60Hz; |
Tag nrho lub zog | 600W; |
Zaub | 2.8 nti npo zaub, tuaj yeem thim rov qab 180 degree; |
Xim lub log | 11 xim ntxiv rau dawb (CTO thiab CMY OPTIONAL). |
Tsau gobo | 17 gobo plus dawb |
Rotation pob | 9 gobo plus dawb, hloov tau; |
Beam Angel | 4-37 degree ; USB connector tuaj yeem teeb tsa DMX chaw nyob nrog lub zog thiab txhim kho cov software. |
Dimmer | 0-100 feem pua linear hloov; |
Pan | 540 degree; 8 ntsis / 16 ntsis; |
Tilt | 270 degree; 8 ntsis / 16 ntsis; |
Tus nqi IP | IP20; |
Khoom loj | 440X310X680mm; |
Flycaes | 930X520X910mm (Tsis suav Log); |
Thawv thawv | 540 X 450 X 650 mm |
N.W | 20KG; |
G.W | 92KG (nrog flycase 2 hauv 1) |
G.W | 25KG (thawv lub thawv). |
